EnGenius EAP150 11b/g/n 150Mbps Indoor Wireless Ethernet Access Point/WDS

Gigabit wired EAP350 offers a "smoke detector" look, and is a high-powered (up to 29dBm) wireless-n access point / WDS Bridge / WDS AP operates seamlessly in the 2.4GHz frequency spectrum supporting 802.11 b/g/n standard high speed feature. It is the best way to add long range wireless capability to your existing wired network or to add bandwidth to your wireless installation.

EAP350 features high wireless output power and receive sensitivity along with antenna diversity. High output power and high sensitivity extend wireless coverage to reduce the roaming between access points and to provide a reliable wireless connection. Gigabit Ethernet port offers faster data transferring and it is ideal for HD gaming and video streaming.

To protect your wireless connectivity, it can encrypt all wireless transmissions through 64/128bits WEP data encryption and also supports WPA/WPA2. The MAC address filtering lets you select exactly which stations should have access to your network. In addition, the user isolation function can protect the private network between client users. The attractive design, high performance and Gigabit wired make the EAP350 a suitable wireless solution for your residence or office.

Brand

EnGenius

Model

EAP350

Standards

IEEE 802.11b/g/n, IEEE 802.3/3u/3ab, 802.3af PoE

Wireless Data Rates

Up to 300Mbps

• WEP Encryption - 64/128 bit
• WPA Personal (WPA-PSK using TKIP or AES)
• WPA Enterprise (WPA-EAP using TKIP)
• 802.1x Authenticator
• SSID broadcast enable/disable
• MAC Address Filter(AP mode)
• WLAN L2 isolation(AP mode)
• Wireless STA (Client) connected list (Idle/Connection Time, Pkt statistics)

Security

WPA/WPA2

WPA2

Frequency Band

2.4GHz - 2.484GHz

Channels

11 Channels

Antenna

Embedded omnidirectional antenna (5 dBi)

• 802.11b (2.412 ~ 2.472 GHz) best <= -98 dBm
• 802.11g (2.412 ~ 2.472 GHz) best <= -93 dBm
• 802.11n (2.412 ~ 2.472 GHz) best <= -93 dBm

Receiver Sensitivity

• OFDM: BPSK, QPSK, 16-QAM, 64-QAM
• DBPSK, DQPSK, CCK

Modulation

Interface

Ethernet Port

• Power/Status
• LAN (10/100/1000Mbps)
• WLAN (Wireless connection)

LEDs

Buttons

Reset Button

Ports

1 x 10/100/1000M

• Power Supply: 90 to 240 VDC +/- 10%, 50/60 Hz (depends on different countries)
• Active Ethernet (Power over Ethernet, IEEE802.3af)
• 48 VDC/0.375A
• Device: 12V/1A

Power Adapter

• Diameter: 4.73" (120mm)
• Height: 1.97" (50mm)

Dimensions

Weight

0.62 lbs. (280g)

Temperature

0°C - 50°C (32°F - 122°F)

Humidity

90% Maximum, Non-Condensing

• Gigabit wired, Business Class Indoor High-power Long-range 800mW (29dBm) Wireless-N Access Point/WDS Bridge/WDS AP with Smoke Detector Housing and 802.3af PoE Support

• MCU/RF: AR7242+AR9283

• Memory: 32 MB

• Flash: 4 MB

• Topology: Infrastructure/Ad-Hoc

• Operation Mode: Access Point/WDS Bridge/WDS AP

• Multiple BSSID: Supports up to four BSSIDs

• LAN: IP (check validity and DHCP server IP range) MAC

• DHCP Server: DHCP range, lease time, client list

• VLANs Supports:
• 802.1q (up to four VLANs)
• SSID to VLAN mapping

• Spanning Tree: Supports 802.1d Spanning Tree Protocol

• VPN: VPN pass-through (PPTP, L2TP, IPSEC)

• QoS: WMM

• WPS: Software only

• High-power, Long-range Wireless-N

• Wireless-N up to 6x Speed over Legacy 11G Networks

• SSID to VLAN Mapping

• 802.3af PoE Compliant
